Commercial and industrial, Mixed-use development · Project location: 10804 Hull St Rd N North, Midlothian, Virginia · United States
A master plan for a commercial development, arranging display and retail units around a central landscaped green with parking, service access and planted frontages to the highway.
The plan organises a corner site with two road frontages: units are grouped around an internal circulation loop and a central green, parking and servicing are set behind the frontage, and planting is used to structure the edges and entrance points.
Master plan preparation and technical documentation by Ideeplan Consult, checked by Tpl. Idibeke Ekott, Principal Consultant.
Static project outputs prepared for this commission. Illustrative visuals, where used, are labelled in the caption.
The following details are withheld because they are unverified or not cleared for publication:
Project title, address, client, date, software, scope and imagery supplied and approved for publication by Ideeplan Consult (project details document). No outcome or approval status is claimed.
